Features
- IP 65 Rating for motor (Dust tight & water spray proof)
- DTC Fault detection
- Blue Vision headlamp
- Convenient charging port location behind driver cabin
- Hill Hold Assist / Hill Descent Control
- Cloud Based Mobility
- 100% Electric – Zero Noise and Emission
- Very Low Maintenance
- Regenerative braking system
- Automatic Gearbox
- Full Digital Instrument Cluster
- Limp home mode
- Economy and Boost Mode
- Low charge indicator
- 5% Emergency Reserve
Vehicle Specs
| Motor – Peak | 9.5 kW |
| Battery capacity (kWhr) | 8.0 kWhr |
| Gearbox | 10.3:1 |
| Charger | 3 kW |
| Charging time | 4.00 hrs |
| Attributes | |
|---|---|
| Vehicle Category | LSN |
| Seating Capacity | Driver only |
| Battery & Power | |
| Battery Type, Voltage | Lithium lon, 51.2 V |
| Battery Capacity | Rated: 8 kWh |
| Peak Power | 9.55 kW @ 3500 rpm |
| Peak Torque | 45 Nm |
| Transmission | |
| Transmission Type | PT gear with differential [Integral] |
| Suspension & Brakes | |
| Front | Helical Spring with dampener |
| Rear | Rubber Spring with dampener |
| Steering | Handle Bar type |
| Brake | Drum Brake hydraulically actuated [Front and Rear] |
| Tyre | 120/80 R12 |
| Exterior | |
| Container | Sheet Metal steel cargo container |
| Dimensions | |
|---|---|
| Wheelbase | 2100 mm |
| Overall Width | 1490 mm |
| Overall Length | 3315 mm |
| Overall Height | 1770 mm |
| Minimum Ground Clearance | 220 mm |
| Cargo Box Dimensions (LxWxH) | 1830 mm X 1400 mm X 285 mm |
| Weights | |
| Gross Vehicle Weight [With Battery) | 975 kg |
| Vehicle Kerb Weight | 480 kg |
| Performance | |
| Top Speed | 50 km/hr |
| Typical Driving Range (On Road] | 115±5 kms |
| Gradeability | 19% |
| Home Charger | |
| Type | 48 V/3000 W Off-board charger |
| Charge Duration | 3 hours, 45 mins |
